BME 22s+ Fiber Optic Splicing Machine – Fully Automatic

BME 22s+ Fiber Optic Splicing Machine – Fully Automatic - Image 2

BME 22s+ Fiber Optic Splicing Machine – Fully Automatic - Image 3

BME 22s+ Fiber Optic Splicing Machine – Fully Automatic - Image 5

BME 22s+ Fiber Optic Splicing Machine – Fully Automatic - Image 6

BME 22s+ Fiber Optic Splicing Machine – Fully Automatic

Name: BME 22s+ Fiber Optic Splicing Machine – Fully Automatic
Brand: TechPotli
SKU: 19401
Price: 72500 INR
Availability: InStock
Rating: 5 (1 reviews)

Original price was: ₹99,000.00.Current price is: ₹72,500.00.

Function Type	Semi Automatic
Usage/Application	Splicing Fiber
Dimensions	200mm (L) 123mm (W) 95mm (H) /1.60KG (Including battery )
Return Loss	>60 dB
Question	8kg

4 motors Core alignment Touch screen Electrode life -5000 Duat proof Splicing time 6sec Heating time 18sec

Compare

Description
Reviews (0)

BME 22s+ Fiber Optic Splicing Machine – Fully Automatic

Typical Splice Loss	G651: 0.01dB; G652: 0.02dB; G653: 0.04dB; G655: 0.04dB; G657: 0.02dB
Return Loss	＞60dB
Splicing Program	40 modes
Operation Mode	Manual/ Auto
Auto-Heating	Available
Splicing Time	7~12 seconds
Heating Time	20~26 seconds for 40mm and 60mm shrinkable sleeves
Fiber Magnification	320X(X or Y view), 160X(X and Y view)
Viewing Display	Dual high sensitivity camera, 4.3”HD color LCD touch screen
Data Storage	8000 groups fusion records
Loss Evaluation	Available
Tension Test	1.8～2.2N
Interface	GUI menu interface, easy for operation
Battery Capacity	Detachable 5200mAh Li-battery , typical 250 cycles splicing and heating
Power Supply	Adapter, input: AC100~240V(50/60Hz), output: DC11~13.5V
Electrode Life	More than 4000 ARC discharges, easy to replace
Terminal	USB 2.0 port, for software upgrading, records exporting
Operating Condition	Altitude: 0~5000m; Humidity: 0~95%; Temperature: -10°C~+50°C; Max wind: 15m/s
Dimension/Weight	200mm(L)×123mm(W)×95mm(H)/1.66kg(with battery)
