Tp-Link InSight S655I 1.4mm Fish Eye Camera

The Tp-Link InSight S655I 1.4mm is a 5MP IR fisheye network camera offering 360° panoramic coverage, advanced video analytics, and robust durability with IP67 and IK10 ratings. It supports two-way audio, multiple display modes, and efficient H.265+ video compression, making it ideal for comprehensive surveillance in diverse environments.

The Tp-Link InSight S655I 1.4mm with its 1.4mm ultra-wide lens is an advanced IP camera designed to provide panoramic surveillance coverage for various settings, including large indoor areas and outdoor locations. Tp-Link InSight S655I 1.4mm camera’s broad field of view enables you to monitor wide spaces with a single device, making it highly effective for open areas like warehouses, parking lots, and spacious offices.

The Tp-Link InSight S655I 1.4mm IP Camera is a robust choice for wide-area surveillance that demands clarity, range, and durability. Tp-Link InSight S655I 1.4mm comes With its ultra-wide lens, HD video, and dependable night vision, this camera is ideal for both residential and commercial security needs.

• 5MP Super-High Definition and IR Night Vision
• 360° Coverage without Blind Spots
• Supports Multiple Display Modes^△ and ePTZ
• Supports Ceiling Mount / Wall Mount / Pendant Mount^§
• Smart Detection
• Smart Video Enhancement Technology
• Built-In Microphone & Speaker
• IP67 Waterproof and IK10 Vandal-Proof
• H.265+ Compression Technology
• Suitable for Indoor Wide Areas like Retail Shops and Offices


  Brand Name	Tp-Link
  Model Name	InSight S655I 1.4mm
  Dimension(cm)	5.2 × 5.2 × 2.2
  Weight(kg)	0.48

  CAMERA
  Image Sensor	1/2.7” Progressive Scan CMOS
  Shutter Speed	1/3 to 1/10000 s
  Slow Shutter	Yes
  Minimum Illumination	Color: 0.01 Lux; 0 Lux with IR light
  Day/Night Mechanism	IR Cut Filter
  Day/Night Switch	Unified/ Scheduled/ Auto

  LENS
  Type	Fixed Focal Lens
  Focal Length	1.44 mm
  Aperture	F2.0
  FOV	Horizontal FOV: 180°, Vertical FOV: 180°, Diagonal FOV:180°
  Lens Mount	M12*P0.5
  DORI Distance	Detect: 28.8 m (94 ft) Observe:12 m (39 ft) Recognize: 5.7 m (19 ft) Identify: 2.8 m (9 ft)

  Fisheye Display
  Installation	Ceiling Mount; Wall Mount; Pendant Mount§
  Display Mode	• Ceiling Mount: Fisheye, AR Dewarp, 180 Panorama, 360 Panorama Cylinder, 2PTZ, 4PTZ, Fisheye + 8PTZ, Fisheye + 3PTZ, 360 Panorama + 8PTZ, 360 Panorama + 6PTZ, 360 Panorama + PTZ• Wall Mount: Fisheye, 360 Panoramic Unwrap, 360 Panoramic Unwrap+3PTZ, 360 Panoramic Unwrap+8PTZ, 4PTZ, Fisheye + 3PTZ, Fisheye + 8PTZ

  Angle Adjustment (Manual)
  Range	N/A

  ILLUMINATOR
  IR LED	• Quantity: 4 • Range: 30m • Wavelength: 850nm
  White LED	N/A
  Illuminator On/Off Control	Auto/Scheduled/Always on/Always off

  VIDEO
  Max. Resolution	2560 × 1920
  Main Stream	• Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution: 2560 × 1920, 2256 × 1696, 2048 × 1536, 1280 × 960Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. If WDR is on, the frame rate only supports up to 15fps.
  Sub-Stream	• Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution: 640 × 480, 320 × 240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. If WDR is on, the frame rate only supports up to 15fps.
  Bit Rate Control	CBR, VBR
  Video Compression	• Main Stream: H.265+/H.265/H.264+/H.264 • Sub-Stream: H.265/H.264
  H.264 Type	High Profile
  H.264+	Main Stream Supported
  H.265 Type	Main Profile
  H.265+	Main Stream Supported
  Video Bit Rate	• Main Stream: 256 Kbps to 6 Mbps • Sub-Stream: 64 Kbps to 512 Kbps

  Image Settings	• Brightness • Contrast • Saturation • Sharpness • Exposure • WDR, • White Balance • Prevent Overexposure to Infrared Light • HLC Adjustable by Client Software
  Image Enhancement	BLC/3D DNR/HLC/SmartIR
  Wide Dynamic Range	120dB
  SNR	≥ 52 dB
  Image Parameters Switch	Yes
  Privacy Mask	Up to 4 Masks
  ROI	1 Region
  OSD Setting	Yes

  AUDIO
  Audio Communication	Two-Way Audio
  Audio Input	Yes
  Audio Output	Yes
  Audio Compression	Yes
  Audio Sampling Rate	8KHz
  Environment Noise Filtering	Yes
  Audio Bit Rate	64 Kbps(G.711 alaw)

  NETWORK
  Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
  ONVIF	Yes
  API	Open Network Video Interface (Profile S/T/G)
  Simultaneous Live View	3 Main Streams & 3 Sub-Streams
  Client	Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS
  Web Browser	• Google Chrome® 57 and above • Firefox® 52 and above • Safari® 11 and above • Microsoft® Edge 91 and above
  Cloud	Yes
  Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

  ALARM AND EVENT MANAGEMENT
  Smart Event	• Intrusion Detection • Line-Crossing Detection • Region Entering Detection • Region Exiting Detection • Abnormal Sound Detection
  Basic Event	• Motion Detection • Video Tampering Detection • Exception ( Illegal Login)
  Alarm Linkage	• Memory Card Video Recording • Message Push • Audible Warning
  Linkage Method	N/A
  Output Notification	• Message Push • Email Alarm • Upload Capture to FTP

  INTERFACES
  Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
  Alarm	N/A
  Reset Button	Yes
  Power	DC Power Port
  On-board Storage	Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB§
  Built-in Microphone	Yes; Records Anything Going on within a 15-ft Radius of the Camera
  Built-in Speaker	Yes
  Audio	N/A

  GENERAL
  Operating Temperature	-30–60 °C
  Storage Temperature	-40–60 °C
  Operating Humidity	95% or Less (Non-Condensing)
  Storage Humidity	95% or Less (Non-Condensing)
  Package Contents	• VIGI Network Camera • Quick Start Guide • Waterproof Cable Attachments • Mounting Accessories
  Material	Metal
  Net Weight	• 0.44 Kg ( without Mounting Accessories) • 0.48 Kg ( with Mounting Accessories)
  Power Supply	• 12V DC ± 5%, Max. 11.76 W, 5.5mm Coaxial Power Plug • PoE: 802.3af/at, class 0, Max. 12.14W
  Protection	IP67 Weatherproof, IK10 Vandal Proof
  Product Dimensions (L x W x H)	5.2 × 5.2 × 2.2 in (132 × 132 × 56mm)
  Certifications	CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF
