CP PLUS CP-DPS-PD16V2-12D 16 Channel Power Supply

CP PLUS CP-DPS-PD16V2-12D 16 Channel Power Supply – 12V DC Output, CCTV Camera Power Distribution Box, Metal Enclosure, Overload & Short-Circuit Protection

Name: CP PLUS CP-DPS-PD16V2-12D 16 Channel Power Supply – 12V DC Output, CCTV Camera Power Distribution Box, Metal Enclosure, Overload & Short-Circu ...
Brand: TechPotli
SKU: 23729
Price: 1200 INR
Availability: InStock
Rating: 5 (1 reviews)

Original price was: ₹2,100.00.Current price is: ₹1,200.00.

Model: CP-DPS-PD16V2-12D
Type: 16 Channel CCTV Power Supply
Output: 12V DC | Current: Up to 8A
Rated Power: 96W | Efficiency: 86%
Input Voltage: 200–240V AC
Voltage Adjustment Range: 11.4V to 12.6V
Metal Enclosure for enhanced durability
LED Indicators for all 16 channels
Overload & Short-Circuit Protection (Auto Recovery)
Built-in EMI filter to minimize signal interference
Cooling: Free air convection
Cable Compensation Switch for voltage drop adjustment
Leakage Current: <2mA / 240VAC
Operating Temperature: -20°C to +45°C
Dimensions: 186 x 130.5 x 39mm

Compare

Description
Reviews (0)

CP PLUS CP-DPS-PD16V2-12D 16 Channel Power Supply – 12V DC Output, CCTV Power Supply, Metal Enclosure, Overload & Short-Circuit Protection

The CP PLUS CP-DPS-PD16V2-12D CCTV Power Supply is a high-performance 16-channel unit engineered for professional surveillance systems. Delivering stable 12V DC output, it supports up to 8A current across all channels, making it perfect for large CCTV installations. Housed in a durable metal enclosure, this CCTV power supply includes advanced safety features like overload, over-current, and short-circuit protection. It also features LED indicators for each channel, a cable compensation switch, and a built-in EMI filter to reduce electrical interference, ensuring uninterrupted camera operation.

Input voltage	200~240V AC
Output voltage	12V DC
Current Range	0~8A
Rated Power	96W
Ripple & Noise (max.)	120mVp-p
Voltage Adj. Range	11.4~12.6V
Line Regulation	±1.0%
Voltage Tolerance	n/a
Setup Rise time	2500ms, 15ms at full load
Hold Up Time (Typ.)	35ms at full load
Load Regulation	±5.0%
Temperature coefficient	±0.03%/°C (0~50°C)
Frequency Range	47~63HZ
Efficiency (Typ.)	86%
AC Current (Typ.)	2A/220VAC
Inrush Current (Typ.)	Cold Start: 50A/220V AC
Leakage Current	<2mA / 240VAC
Over Load	110~200% rated output power, Protection type: Shut down O/P, recovers automatically
Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500V DC / 25°C/ 70% RH
Working Humidity	20 ~ 90% RH Non-condensing
Vibration	10 ~ 500Hz, 3G 10min./1 cycle, 60min. each along X, Y, Z
Dimension	186(L) x 130.5(W) x 39mm(H)
Store temperature	-20 ~ +85°C
Working temperature	-20 ~ +45°C
Withstand Voltage	I/P-O/P: 1.5KVAC I/ P-FG: 1.5KVAC O/ P-FG: 0.5KVAC
