C-Band 8ft Dish Antenna 18 Ribs (18 Ribs)

C-Band 8ft Dish Antenna 18 Single Ribs (18 Ribs)

The C-Band 8ft Dish Antenna with 18 ribs is a high-gain, large-aperture antenna designed for professional C-Band satellite communication applications. Its robust design and advanced features ensure reliable and high-quality signal reception.

• Antenna Size – 8 ft. 240Cm.
• Modal – C/Ku-240cm
• Antenna Type – Folding
• Feed  – Prime Focus
• f/d Ratio – 0.40
• Focal Length – 28. Inch
• Punch Sheet – Aluminum Sheet
• Total Segments – 12
• Stability AZ 360  Degree EL to 90 Degrees
• Mount – Polar
• Reflector Material – Metal
• Wind load operational – 95 Kmph
• Survival Wind Speed – 120 Kmph
• Polarization – Liner & Circular
• Pointing Accuracy – Better Than + / – 0.2 Deg.
• Operating Frequency  -3.6 GHz. – 13 GHz.
• Pointing – Manual

Gain – 34 db

Approximate Weight. 30 Kgs.

You can get TV channels from C-Band using this C-Band Dish Antenna. It is best suitable for Cable Operators, Broadcasters, and MSOs.
