D-Link DNR-F5116-M5 | 16-Channel 4K Network Video Recorder (NVR) | H.265/H.264, 1 SATA Port, Google Drive & Dropbox Cloud Storage, ONVIF 2.6 Support
The D-Link DNR-F5116-M5 16-Channel 4K Network Video Recorder (NVR) delivers high-resolution video recording, smart playback, and cloud storage support. With H.265/H.264 compression, 3G/4G Wi-Fi connectivity, and up to 10TB HDD support, it’s perfect for scalable home and business security solutions.
The D-Link DNR-F5116-M5 is a powerful 16-Channel 4K Network Video Recorder (NVR) designed for scalable security surveillance. D-Link DNR-F5116-M5 comes with support for up to 16 IP cameras, it delivers high-definition 4K video recording for detailed and clear footage.
D-Link’s Indigenous Series is a range of surveillance solutions designed and manufactured in India, aligning with the government’s ‘Make in India’ initiative. This series includes a variety of IP-based cameras and Network Video Recorders (NVRs) tailored to meet the security needs of Indian consumers.
D-Link DNR-F5116-M5 is featuring H.265/H.264 video compression, this NVR optimizes bandwidth and storage efficiency. D-Link DNR-F5116-M5 has a SATA port supports up to a 10TB HDD, making it ideal for long-term recording needs. The 3G/4G and Wi-Fi connectivity provide flexible remote access, ensuring you stay connected to your surveillance system at all times.
D-Link DNR-F5116-M5 comes with Smart Video Analytics, users benefit from motion detection, tampering alerts, and intelligent playback features. The Google Drive & Dropbox cloud storage support ensures secure backup options, while ONVIF 2.6 compatibility allows integration with a variety of IP cameras.
Perfect for homes, offices, retail stores, and enterprises, the DNR-F5116-M5 offers efficient, high-quality video recording with advanced security features for comprehensive monitoring and peace of mind
Key Features:
✔ 16-Channel 4K NVR – Supports up to 16 IP cameras with ultra-HD 4K recording.
✔ H.265/H.264 Video Compression – Efficiently saves storage and bandwidth while maintaining high quality.
✔ Smart Playback & Video Analytics – Includes motion detection, tampering alerts, and advanced AI-driven features.
✔ 1 x SATA Port (Supports up to 10TB HDD) – Provides ample storage for extended surveillance recordings.
✔ 3G/4G & Wi-Fi Connectivity – Ensures flexible network access for remote monitoring.
✔ Cloud Storage Support – Easily backup and store footage on Google Drive & Dropbox.
✔ ONVIF 2.6 Support – Ensures seamless integration with a wide range of IP cameras.
✔ Remote Access & Backup – View live and recorded footage anytime, anywhere via web and mobile apps.
| Specification | Details |
|---|---|
| Network Video Input | 16CH |
| Operating System | Embedded Linux |
| Network Access Bandwidth | 80 Mbps |
| Video Compression | H.265 / H.264 |
| Video Output | 1x VGA output (1920×1080@60Hz, 1280×1024@60Hz) 1x HDMI output (3840×2160@30Hz, 1920×1080@60Hz, 1280×1024@60Hz, 1440×900, 1280×720, 1024×768@60Hz) |
| Video Preview Mode | 16CH, 5MP Preview |
| Video Bit Rate | 16Kbps–16Mbps |
| Video Resolution | 8MP/5MP/3MP/1080P/720P/D1/VGA/CIF/QCIF |
| Preview Capability | 8×4K/25fps (Mainstream), 16×D1/25fps (Sub Stream) |
| Audio | 1x Audio Output |
| Image Display | 1/4/8/12/16 image Displays |
| Snapshot Mode | Timing snapshot, manual snapshot, JPEG format |
| Motion Detection | Supports 396 (22×18) surveyed areas with multi-level sensitivity adjustment |
| Privacy Mask | Supports 4 zones |
| Audio Compression | G.711u/a |
| Audio Output | 1x RCA |
| Video Frame Rate | 1–30 FPS |
| Record Mode | Manual, Schedule, Motion Detection, Timing, Intelligent Analysis Alarm, Smart Motion Detection |
| Playback Ability | Supports 16CH playback |
| Playback Mode | Local video, External file playback |
| Record Search | Time, Calendar, Channel Search, Event Search (Regular Video, Motion Detection Video, Alarm Event Video) |
| Event Actions | Send Email, Audible Warning (Buzzer), Alarm On Monitor, Record, Snapshot, Preview, PTZ Linkage |
| Video Playback | Start, stop, normal play, back play, forward 30 seconds, backward 30 seconds, fast play (1–256X), slow play (1–1/32X), frame play, display progress bar, backup, snapshot, full screen, precise playback |
| User Management | User Add, Delete, Modify, Permission Management, Dual Password Authentication, Zero Passage, Auxiliary Users (Secondary Password Protection) |
| Storage Interface | 1x SATA |
| HDD Capacity | Single max. 10TB |
| Backup Location | Local, Network |
| Backup Method | USB Device, Network backup |
| Network Interface | 1x RJ45 10M/100M adaptive Ethernet port |
| USB Interface | 2x USB2.0 |
| Network Protocol | TCP/IP, IPv4, HTTP, PPPoE, DHCP, DNS, 3G/4G, Wi-Fi, Google Drive/Dropbox Storage, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, FTP, P2P, IP Filter, HTTPS |
| Interface Protocol | ONVIF, RTSP |
| Protocol Port | ONVIF/RTSP/HTTP |
| Mobile Surveillance | Supports iOS, Android |
| Power Supply | DC 12V 2A |
| Power Consumption | ≤10W (Without HDD) |
| Operating Temperature/Humidity | -10°C to 60°C / 10% to 90% non-condensing |
| Dimensions | 192mm × 192mm × 42mm |
| Weight | 340 g |
| Certification | CE, BIS Certified |
