Deviser OTDR AE3100DM –Optical Time Domain Reflectometer Quad Wavelength Optical Time Domain Reflectometer

OTDR Deviser AE3100DM – Advanced Optical Time Domain Reflectometer for Fiber Testing

The OTDR Deviser AE3100DM is a powerful and portable fiber testing tool designed for both single-mode and multimode fiber networks. With quad-wavelength support (850/1300/1310/1550nm), a high dynamic range of up to 40dB, and an ultra-low event dead zone of 0.8m, this device delivers professional-grade performance for FTTx, RFoG, and LAN applications.

✅ Key Features:

• Quad Wavelength Support: 850nm / 1300nm / 1310nm / 1550nm for wide application compatibility

• Dynamic Range: Up to 40dB for accurate long-distance fiber testing

• Event & Attenuation Dead Zone: Just 0.8m and 4m (single-mode), ideal for detecting close events

• 7” Touchscreen Display: 800×480 resolution with intuitive navigation

• Minimum 5cm Resolution: Detects fine fiber issues

• FiberPath™ Mapping: Visual link map for simplified interpretation of OTDR traces

• Built-in Tools: Optical power meter, visual fault locator (VFL), light source, fiber microscope

• Fast Refresh Rate: 4 fields/second with real-time data processing

• Data Storage: Store over 10,000 OTDR traces; export via USB or LAN

• Remote Management: Sync with SYNCOR system for field deployment and data retrieval
