Key Features
- Supported OS’s: Android/ Windows/ WinCE/ Linux/eLinux/ Mac/proprietary OS/ Non-OS
- Supported interface connections: USB
- NIST-proven extremely accurate iris image quality assessment algorithm
- Secure data & communication: Each IriShield device has its own 2048 bit RSA key securely generated on-board for encryption and digital signature.
- Tamper-proof
| General | |
| Video User Guide | View Here |
| Ancillary SW | Drivers, SDK (C/C++, .NET, C#/VB, Java), Demo Application with Sample codes |
| Host OS | Windows Family, Linux Family, WinCE, Embedded Linux, Android, Mac, proprietary OS or Non-OS |
| Connectivity | USB 2.0 |
| Security | RSA (2048-bit) and AES (256-bit); X509 Certicate, PFX/PKCS#12 Certicate, RSA key pair generated on-board |
| Compliance&Certifcates | Eye safety standard (IEC 62471:2006-07), RoHS, FCC-Class B, IP54 |
| Resolution | Spatial : 50% @ 3.5 Lp/mm, Pixel : 16 Pixels/mm |
| Environmental | -20°C to +60°C (Storage); 0°C to +50°C (Operating); 10% to 90% Humidity (Non-Condensing)* |
| Usage | Indoor; Outdoor (avoid direct sunlight and bright reections) |
| Min. Illumination | Near infrared LED |
| sensor Resolution | VGA |
| Dimensions | 51.2 mm x 92.6 mm x 15.1 mm (2 inches x 3.6 inches x 0.59 inch) |
| Power | Single USB Bus Powered (DC +5V±5%) (Max power consumption = 300mA) |
| Capture Distance | 14.0 cm – 15.0 cm (5.5 inches – 6.0 inches) from the image sensor (optimal distance = 14.5 cm (5.7 inches)), Focal depth = 1.0 cm (0.4 inch) |
| Capture Mode | Auto |
| Downloads | Click Here |
