SECUREYE S-OLT-EPON 4 Port L3
Original price was: ₹29,500.00.₹23,999.00Current price is: ₹23,999.00.
100 in stock
Compare- Description4 PON Port EPON OLT with L3 Function
- Model NoS-OLT-EPON-4OLT-L3S
- Key Features
- 4*EPON Port, 4*GE(RJ45) Port and 4*10GE(SFP+) Port. It can support 256 ONU under 1:64 splitter ratio
- In compliant with IEEE802.3ah Standard
- Up to 20KM transmission Distance
- Support data encryption, group broadcasting, port Vlan separation, RSTP, etc.
Products Overview:
S-OLT-EPON-4OLT-L3D EPON OLT product is a 1U chassis device with L3 function developed by Secureye. It complies with IEEE802.3ah standard, compatible with mainstream brand ONU access, easy to build EPON network flexibly and efficiently. It is smart, easy to deploy, and high performance, meeting the performance and volume requirements of users in different environments, and It also supports rich operation and maintenance tools such as EMS, WEB, Telnet, SSH and mobile APP, provides users with stable, efficient and value-added network access services. The product is suitable for “Triple-Play”, CPN, IP Camera, Enterprise LAN and IOT applications.
Satisfactory standard
Meet IEEE802.3ah standards
Support IPv6 Function
Support DN, IPv6 Ping, IPv6 Telnet
Support ACL based on source IPv6 address, destination IPv6
address, L4 port, protocol type, etc.
Support MLD v1/v2 snooping
IP route
Support static route, dynamic route RIP v1/v2、OSPF v2(optional)
Easy to manage
Friendly EMS/Web/Telnet/CLI/SSH management
CLI command style similar to mainstream manufacturers
Support APP management
Fully open platform
Open to any brand of ONU
High performance cost
1U height compact design
Adopt mainstream chip scheme
Specifications
| Chassis | |
| Rack | 1U 19 inch standard box |
| 1G, 10G uplink Port | |
| QTY | 8 |
| 1G copper port auto-negotiable(RJ45) | 4 |
| SFP 1GE / SFP+ 10GE | 4 |
| EPON Port | |
| QTY | 4 |
| Physical Interface | SFP Slot |
| Connector Type | PX20+ |
| EPON Port | |
| Max Splitting Ratio | 1:64 |
| Management Ports | |
| Management Ports | 1*10/100BASE-T out-band port, 1*CONSOLE port |
| PON Port Specification (PX20+ module) | |
| Transmission Distance | 20KM |
| EPON port speed | Upstream 1.25G, Downstream 1.25G |
| Wavelength | TX 1490nm, RX 1310nm |
| Connector | SC/UPC |
| Fiber Type | 9/125μm SMF |
| TX Power | +2~+7dBm(PX20+) |
| Rx Sensitivity | -30dB(PX20+) |
| Saturation Optical Power | -6dBm |
| Dimension(L*W*H) | 442*200*43 |
| Weight(kg) | 3.2 |
| Power Supply | AC 100～240V, 47/63Hz |
| Power Supply | DC -48V |
| Double Power Module | X √ |
| BBU(Battery Backup Unit) | X √ |
| Max Power Consumption | 30W |
| O p e r a t i n g Environment: | |
| Working Temperature | 0～+50℃ |
| Storage Temperature | -40～+85℃ |
| Relative Humidity | 5~90%(non-conditioning) |
