Syrotech GOXS-BI3503-20D Syrotech GOXS-BI5303-20D LC | Single Fiber SFP Bi-Directional Module (Combo) 20Km

Syrotech GOXS-BI3503-20D and GOXS-BI5303-20D LC are 1.25G bidirectional SFP modules, providing 20KM long-range connectivity over single-mode fiber with LC connectors, perfect for high-performance data transmission.

Syrotech GOXS-BI3503-20D and GOXS-BI5303-20D LC are bidirectional 1.25G SFP modules designed for long-range fiber optic communication over a single fiber. Offering a 20KM transmission range, this combo module allows for both transmit and receive data transmission on the same fiber, optimizing network infrastructure and reducing cable requirements. With LC connectors for easy installation, these modules are ideal for high-speed, long-distance applications in telecommunications, data centers, and enterprise networks. They ensure efficient, reliable, and high-performance connectivity while complying with industry standards for seamless integration with networking equipment.

The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of
125Mbps/155Mbps and 20km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a
trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety
requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further
information, please refer to SFP MSA.

Dual data-rate of 155Mbps/125Mbps operation

* 1310nm FP laser and PIN photo detector for 20km transmission
* Compliant with SFP MSA and SFF-8472 with single LC receptacle
* Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
* Compatible with RoHS
* +3.3V single power supply
* Operating case temperature:
Standard : 0 to +70°C
Industrial : -40 to +85°C
