Syrotech GOXS-BI4503-80D Syrotech GOXS-BI5403-80D | Single Fiber SFP Bi-Directional Module (Combo) 80Km

Syrotech GOXS-BI4503-80D and Syrotech GOXS-BI5403-80D are 1.25G bidirectional SFP modules offering 80KM long-range connectivity over single-mode fiber, ideal for efficient, high-performance data transmission.

Syrotech GOXS-BI4503-80D and Syrotech GOXS-BI5403-80D are 1.25G bidirectional SFP modules designed for high-performance, long-range fiber optic communication, supporting a transmission distance of up to 80 kilometers. These modules enable both transmit and receive functions over a single fiber, helping to simplify network infrastructure and reduce the need for additional cabling. The modules are ideal for use in telecom, data centers, and enterprise networks, offering efficient and reliable data transfer with minimal signal degradation. Compatible with a variety of networking devices, these modules are equipped with SC or LC connectors for easy installation and integration.

The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of
125Mbps/155Mbps and 80km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a
trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety
requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further
information, please refer to SFP MSA.

Dual data-rate of 155Mbps/125Mbps operation

* 1310nm FP laser and PIN photo detector for 20km transmission
* Compliant with SFP MSA and SFF-8472 with single LC receptacle
* Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
* Compatible with RoHS
* +3.3V single power supply
* Operating case temperature:
Standard : 0 to +70°C
Industrial : -40 to +85°C
